Ensure the performance of transformer insulating oil

In the high-humidity, high-salt spray environment off the coast of Chile, transformer oil is susceptible to contamination by moisture and impurities. Through vacuum dehydration, degasification and multi-stage filtration technology, the dielectric oil treatment machine deeply removes moisture (which can be reduced to less than 5ppm) and particulate impurities (with an accuracy of 5μm) in the oil, significantly improving the dielectric strength of the oil (typical increase of up to 30%), and ensuring the safe operation of the transformer in harsh environments.

Support for preventative maintenance of the grid

Chile's power grid has implemented preventive O&M programs (e.g., the "Winter Plan") for extreme weather, such as winter wind disasters. The Transformer Oil Filtering Machine can be operated live online and reduce the frequency of shutdown and maintenance, and improving the reliability of power supply. This feature is particularly useful in areas where the insulation of medium-voltage lines is low, such as Valparaiso.

Adapt to localized power equipment

In response to Chile's industrial three-phase 380V voltage standard, the Transformer Dielectric Oil Filtering Machine exported from China needs to be compatible with the local power supply system. The Dielectric Oil Treatment Machine is designed with a corrosion-resistant shell (to cope with coastal salt spray) and an intelligent temperature control system (dynamic adjustment at 40–80°C) to ensure long-term stable operation of the equipment.

Technical advantages and localization needs

High-efficiency oil-water separation combine micro water droplets into large droplets, with vacuum separation, the efficiency is 3 times higher than that of traditional equipment;

Intelligent operation and maintenance support: integrated online moisture monitoring, automatic sewage discharge and differential pressure protection functions to meet the needs of unattended;

Anti-environmental corrosion design: high-sealing oil storage tank and alloy shell, suitable for high humidity and high salt spray geographical conditions in Chile.
